Measurement Light Curtains
Light curtains for industrial and civil applications where it is necessary to detect, measure, and recognise objects.
Depending on the number and position of the beams engaged by an object, the measurement sensors can provide real time information to a PLC or PC in order to: detect the presence or absence of objects, perform a count, detect a position, detect a shape or a profile, measure dimensions.
Outputs
- AV (0/10 VDC) analogue output,
- AC (4/20 mA) analogue output
- RS 485 serial line
- Solid state antivalent outputs 0/24V
- IO-Link serial communication protocol
Controlled Height
This is the height controlled by the light curtain
Range
This is the maximum working distance that may exist between the emitter and the receiver
Synchronisation
Synchronisation between emitter and receiver Optical or via cable, selectable
Light Curtain Beam Spacing
Distance between the optics of the measurement light curtains. 5, 10, 25, 30, 50, 75 mm
